SUNWAY > Automatic Voltage Regulators > STB 1Kva-12Kva Single Phase Servo Wall Mount Avr For Low Voltage

STB 1Kva-12Kva Single Phase Servo Wall Mount Avr For Low Voltage

The DTB series servo voltage stabilizer is an efficient single-phase voltage stabilization device designed for home use. This series provides two control modes: relay and servo control to meet different user needs. Equipped with a color LED display, it can display the input voltage, output voltage, undervoltage, overvoltage and overload status in real time to ensure that users are aware of the power situation in a timely manner. The DTB series voltage stabilizer has a compact structure and a wall-mounted design, which is convenient for installation on the wall of the home.

Technical Parameters

Model	DTB	STB
	1KVA 1.5VA 2KVA 3KVA 5KVA 8KVA 10KVA 12KVA	1KVA 1.5VA 2KVA 3KVA 5KVA 8KVA 10KVA 12KVA
Phase	Single phase
Input voltage	AC 90-260V or customized
Output voltage	AC 220V or customized
Frequency	50Hz/60Hz
Precision	±10%; ±8%;	±3%
Work efficiency	>95%
Control type	Relay type	Servo motor
Digital display	Show input and output voltage
Protection	Over/Under Voltage, Over Load, Short Circuit, Over Temperature
Ambient temperature	-10°C~+ 40°C
Noise level	≤50dB
Transformer Wire	Copper or Aluminium
USB Charger	Optional
Display	Digital and Analog Meter
